Bandsaw & Shape Cuts

Top quality thanks to professional processing

Company Damatech has extensive facilities for processing prehardened steel grades exactly in line with customer requirements: narrow cutting tolerances, reliable and top quality manufacturing. Damatech Company offers bandsaw cutting, abrasive water jet cutting, flame and plasma cutting.

Thanks to our sophisticated warehousing, logistic, and IT system, materials are delivered to customers just in time. In addition to wide-ranging materials and services, Damatech also offers end-to-end warehousing and inventory management, as well as customized supply chain solutions.

Saw Cuttings

Rectangular blanks sawn from our stock range delivered inside 3 working days

Saw cutting is a proven cutting process for plates made of pre-quenched and tempered tool and mechanical engineering steel. Depending on the requirements, workpieces with a thickness of up to 250 mm, a width of up to 2,500 mm and lengths of up to 8,000 mm can be sawn cleanly and with the tightest tolerances – without the hardening in the edge zones that often occurs in thermal cutting processes.

Advantages of Precision Saw Cutting Compared to other metal cutting methods, precision saw cutting offers several advantages, such as:

No heat damages (cutting edge hardening, cracking, microstructure changes)
Reduced material waste (due to closer -tolerance cutting)
Quicker turnaround (without sacrificing cut quality)
higher quality cut finishes

The sawing process is carried out on state-of-the-art band saws and longitudinal panel saws.

Shape Cut Pieces

Waterjet blanks made of pre-hardened steel is the way how to save time and costs in mechanical processing

Waterjet cutting is one of the cold cutting processes and enables the separation of sheets and plates made of a wide variety of materials up to more than 160 mm. With waterjet cutting, no heat effective zones are caused.

Particular advantages of water jet cuttings are:

no heat damages (hardening, cracking, microstructure changes)
no deformation and additional residual stresses
blanks with the excellent cutting surface and cutting tolerances

The range of services includes the production of blanks according to your drawing in DXF or CAD format with the highest precision.

Plasma blanks

Plasma blanks with holes, countersinks and threads manufactured in one step.

Cost-effective and precise cuts up to a material thickness of 40 mm. The attachment of holes, countersinks, threads and chamfers up to 45° is also possible with this process.

Benefits at a glance

the most cost effective cutting process in the plate thickness range between 10 and 40 mm
highest cutting speeds by thicker plates
Very smooth cutting surfaces regardless of plate steel grade

The range of services includes the production of blanks according to your drawing in DXF or CAD format with the highest precision.

Oxy-fuel Parts

Oxyfuel flame cutting is the most economical process for cutting heavy plates

Oxyfuel cutting is ideal for heavy plates in the upper thickness above 50 mm, which conventional cutting processes cannot handle. In addition, despite the high sheet thickness, this process produces vertical cut edges. Especially for the cutting of pre-hardened steel grades, the process represents an economical alternative.

Positive aspects of oxy-fuel cutting
